Product Description:

♦ Material characteristics: Wafer iron rings are usually made of iron or other metal materials, which have strong mechanical strength and good corrosion resistance.

♦ Structural design: The structural design of the wafer iron ring is simple and effective, which can accurately fix the wafer and prevent displacement or damage during processing or testing.

Features:

Note:

♦ Cleaning and maintenance: Regularly clean and maintain to ensure the performance and service life of the iron ring.

♦ Proper use: according to different processing steps, use the iron ring correctly to avoid damage to the wafer.

♦ Quality control: Strictly control the quality of the iron ring to ensure its stability and reliability during use.

Advantage:

♦Extensive application: Wafer ferrules are used in many aspects of semiconductor manufacturing, and ferrules play an indispensable role from wafer cutting, polishing to packaging. Its use greatly improves the efficiency and quality of semiconductor manufacturing.

♦High-temperature tolerance: In the process of semiconductor manufacturing, the wafer needs to experience harsh environments such as high temperature, and the iron ring of the wafer needs to have good high-temperature tolerance to ensure that it will not be deformed or damaged at high temperature.

Packing and Shipping:

Adopt moisture-proof, shock-proof and pressure-proof packing method.

• Choose sturdy cartons, wooden boxes or iron drums and other packaging containers.
• Fill the interior with cushioning materials such as foam, bubble bags,Label the outer package with product information, delivery address, etc.

​Choose a regular international logistics company.

• According to the mode of transportation (sea, air, etc.) to do a good job of storage, loading and unloading
• Maintain temperature and humidity control throughout the transportation of goods. Properly handle the return and exchange of goods due to transportation damage.
