Product Description:

---

• Safe and Efficient Wafer Shipping and Storage:

​At Horizontal Wafershipper, we are dedicated to providing the most secure and efficient methods for wafer shipping and storage. Our advanced product design ensures the safety of your wafers during transportation and storage.

• Wafer Package System

Our Wafer Package System is the ideal solution for transferring wafers safely and efficiently. With a proven technology developed through years of experience, this system is capable of handling even the most delicate wafers, including thin wafers for TSV chips and compound wafers.

• Conductive and Shock-Resistant Wafer Carrier

Our wafer carrier is designed to protect your wafers from various potential risks. It is conductive, ensuring a clean and safe environment for your wafers. Its shock-resistant feature protects against damage during transport and storage. The compact and stackable design also allows for efficient wafer shipping.

• Low Ionic/Outgassing Material for Maximum ProtectionMade from low ionic/outgassing wafer Grade PP material, our wafer carrier is ESD safe for maximum protection of your wafers and devices during transportation and storage.

Features:

---

• Product Name: Wafer Carrier Box
• Advantage: Superior Wafer Protection
• Material: Conductive PP
• Property: ESD
• Incoterms: EXW,FOB,CIF,DDU,DDP
• Wafer Shipping Box
• Packing Silicon Wafer
• Anti-static

Technical Parameters:

---

---

Property	Value
Product Name	Wafer Carrier Box
ESD	Yes
Advantage	Superior Wafer Protection
Design	Ergonomic Open/Close Design
OEM/ODM	Accept Customization
Material	Conductive PP
Cleanliness	Clean Room Use(Cleaning And Packing)
Product Name	Wafter Handling Shipping
Color	Black
Name	Wafter Shipping Canisters
Size	8 Inch

Applications:

---

• Transportation between manufacturing facilities
• Storage in warehouses
• Transportation to and from testing facilities
• Safe packaging for shipping and delivery
• Semiconductor manufacturing
• Electronic devices production
• Solar panel production
• Optical and electronic equipment production

Why Choose Hiner-pack's Wafer Carrier Box?

• Our product has been certified by ROHS, LPC and IC Report, ensuring its quality and safety for transporting valuable wafers.
• The minimum order quantity is negotiable, allowing for flexibility in purchasing.
• We offer competitive pricing based on delivery methods and quantities.
• Our packaging details include double packing after cleaning, providing extra protection for your wafers.
• With a supply ability of 300~500 sets per day, we can meet the needs of large orders.
• The ergonomic open/close design makes it easy to access and handle the wafers.
• Our product is suitable for use in ordinary environments, ensuring its cleanliness and safety for your wafers.
• We accept customization for OEM/ODM orders to meet specific requirements.
• The black color of our Wafer Carrier Box adds a professional and sleek look to your packaging and transportation process.

• Technical Support

Our team of experts is committed to providing top-notch technical support for the Wafer Carrier Box. We have in-depth knowledge of its design, materials, and functionality, allowing us to assist with any technical issues or questions you may have.

• Design Consultation

Our team can provide design consultations to help you determine the best Wafer Carrier Box for your specific needs. We can also offer suggestions for customization to meet unique requirements.

• Material Selection

We understand the importance of selecting the right materials for the Wafer Carrier Box. Our team can provide guidance on material selection based on the type of wafer, environment, and handling conditions.

• Troubleshooting

In the rare event that you experience any issues with your Wafer Carrier Box, our team is available to troubleshoot and provide solutions to resolve the problem.
